Working Area

1300 X 2500 X 600 MM/1500 X 3000 X 600 MM

Control Sysytem

Rich Auto A11E / NK 105G3 Controlling System

Spindle

4.5 KW/6 KW/7 KW Water Cooling Spindle

Spindle speed

0-24000 RPM

Machine Body and Gantry

Heavy Duty Metal Welded Structure

Table

Aluminium T Slot & PVC Table

Driving System

Stepper Motor/Hybrid Servo Motor & Driver/Pure Servo Motor

Rack & Pinion

Helical Rack & Pinion

X Y Z Axis Square Rails

XYZ Axis 25mm Taiwan Hiwin Linear Square Guide

Collets Type

ER 32

Max. Speed

0-20000mm/min

Max. Working Speed

0-10000mm/min

Command

5mm SS Tank

Machine Voltage

AC 380 V / 3 Phase, 50 Hz

Machine Weight

1200 Kg

Machine Software

Artcam

Machine Diamentions

3500 x 2250 x 2130 mm

Lubrication System

Auto Oil Lubrication
