Working Area

1300X2500X300 MM/1500X3000X300 MM (DOUBLE SPINDLE)

Control Sysytem

Rich Auto A11E /NK105G2 (Optional: DSP Hand Controller)

Spindle

3 KW/4.5 KW/6KW

Spindle speed

18000/24000 RPM

Machine Body and Gantry

Heavy Duty Metal Welded Structure

Table

T Slot/PVC Table

Driving System

Stepper Motor/Hybrid Servo Motor & Driver

X, Y, Z Axis Structure

Helical Rack & Pinion

X Y Z Axis Square Rails

XYZ Axis Taiwan Hiwin Linear Square Guide

Collets Type

Er20 3.175-12.7m

Max. Speed

18m/min

Max. Working Speed

12m/min

Command

G code

Machine Voltage

AC 380 V/3 Phase, 50 Hz

Machine Weight

1250 Kg

Machine Software

Artcam

Machine Diamentions

3000 x 2200 x 1900 mm

Lubrication System

Auto Oil Lubrication
