Working Area

2000X3000X450MM/2000X3600X450MM (DOUBLE SPINDLE)

Control System

NK 105G3 Controlling System

Spindle

6 KW/7.5 KW Water Cooling Spindle

Spindle speed

0-24000 RPM

Machine Body and Gantry

Heavy Duty Metal Welded Structure

Table

Aluminium T Slot & PVC Table

Driving System

Hybrid Servo Motor & Driver/1.5KW Servo Motor

Rack & Pinion

Helical Rack & Pinion

X Y Z Axis Square Rails

XYZ Axis 30mm Taiwan Hiwin Linear Square Guide

Z Structure

Ball Screw 2510/30mm Hiwin Linear Square Guide

Max. Speed

0-20000mm/min

Max. Working Speed

0-10000mm/min

Water Bed

1.2mm SS Tray

Machine Voltage

AC 380 V / 3 Phase, 50 Hz

Machine Weight

2500 Kg (Gross Weight)

Machine Software

Artcam Software

Machine Diamentions

4200 x 2250 x 2230 mm

Lubrication System

Auto Oil Lubrication
